Process Chillers for Laser Applications

In the semiconductor and printed circuit board industries, lasers take on a crucial role. Lasers are also increasingly used for the production of flat panel displays, including high-resolution screens for smartphones and tablet computers, as well as large LCD and OLED displays for television sets. Another growing application field for laser micro processing is the production of solar cells, where laser structuring helps to increase cell efficiency. As the laser market evolves, the ability to remove heat becomes a critical challenge. Process chillers have become the main cooling apparatus for the latest generation laser systems.

Legacy manufactures the leading line of laser process chillers.

To make selection of the correct laser process chiller easier, Legacy has developed OEM designs for many of the most popular laser systems. Referring to the tables below, if you don’t see a process chiller that meets the specific cooling requirements of your laser application not to worry, we have dedicated application engineers available to assist you. Just give us a call.

To make your selection of the correct glycol process chiller easier, Legacy has developed OEM designs for many of the most common process chillers used for Brewery’s, Distillery’s and other Fermentation production. If you don’t see Glycol chiller for your specific requirement below, not to worry, we have dedicated process chiller application engineers available to assist you. Just give us a call at 877-988-6464 x 101.

Why Choose a Legacy Process Chiller for your Laser Application?

Laser Process Chiller Statement of Value: Each of our laser cooling chillers are specifically designed to meet the 24/7/365 demands of your laser system. Prior to shipment, each process chiller is load tested while undergoing a rigorous quality control process.

laser

Standard Features

Partial List for Glycol Cooling Applications

-> ETL listed US/C

-> Industrial trade PLC with high resolution touch screen.

->  Closed (SS) storage tank on with separate dedicated recirc pump.

-> Fused, STAINLESS STEEL Process pump w/ discharge ball valve.

-> STAINLESS STEEL, brazed plate evaporator.

-> Hot Gas Bypass Capacity Control.

->  Painted (Powder Coated), galvanized sheet metal cabinet.

->  Low ambient package rated down to 38F.

->  Dedicated recirculation pump proving temp stability to process.

-> QUICK SHIP program available.

-> Built in Web Server with data logging and email alerts.

->  Post metal production powder coat paint.

-> monitor/control from any web enabled device using any web browser.

->  Factory QC under lead prior to ship.

->  Machine bent tubing, 80% less brazed fittings.

->  MANUFACTURED IN THE USA!

->  QUICK SHIP AVAILABLE FOR MOST MODELS

Available Factory Options

Partial List for Glycol Applications

->  E-Coat coastal protection.

->  Low ambient control options down to -20F ambient.

->  Patented Economizer System that can reduce energy usage as much as 60%.

->  BacNet data communications TCP/IP or Serial.

->  Remote wall mounted touch screen.

->  Voltage and Phase monitoring and protection.

->  VFD lead compressor / PLC controlled.

-> VFD System pump / PLC Controlled.

-> VFD head pressure control (Air-Cooled Models).

->  Dual pump with auto changeover / auto lag lead.

->  Many system pump configurations to choose from.

->  Open vented storage tank as alternate to closed SS.

Comment about tables below: Process chiller assignments nested into the tables below are based on available information at the time we generated them. As with many industries, technical characteristics are very dynamic, tending to change often. As such ALWAYS check with your Legacy Process Engineer prior to specifying or purchasing your process chiller. The operating conditions used to assign process chillers in the tables below are 95F ambient (Air-Cooled) and 105F condensing (or 75F entering water temp for Water-Cooled) and 45F leaving WATER ONLY temp going to the process. If your conditions vary from these industry standards, please contact Legacy Chiller Systems (877-988-5464 x 101) for an updated selection.

In the table provided below you will find our current list of process chillers for laser research & development applications.

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
PZAPT1SPZAPT1S16,800 BTUH36.034.049.0350.0
PZAPT2SPZAPT2S26,400 BTUH36.034.049.0425.0
PZAPT2.5SPZAPT2.5S36,000 BTUH36.034.049.0475.0
PZAPT3SPZAPT3S38,400 BTUH46.034.055.0425.0
PZAPT4SPZAPT4S43,200 BTUH46.034.055.0525.0
PZAPT5SPZAPT5S58,800 BTUH46.034.055.0575.0
PZAPT7SPZAPT7S91,200 BTUH75.034.055.0700.0
PZAPT8SPZAPT8S102,000 BTUH75.034.055.0700.0
PZAPT9SPZAPT9S117,600 BTUH75.034.055.0750.0
PZAPT11SPZAPT11S123,600 BTUH75.034.055.0875.0

In the table provided below you will find our current list of process chillers for production and OEM laser applications.

Air-Cooled Process Chillers, Packaged, Single Stage Scroll, with Tank

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
PZAT1SPZAT1S14,000 BTUH36.034.068.0550.0
PZAT1.5SPZAT1.5S18,000 BTUH36.034.068.0600.0
PZAT2SPZAT2S22,000 BTUH36.034.068.0650.0
PZAT2.5SPZAT2.5S28,800 BTUH36.034.068.0700.0
PZAT3SPZAT3S36,000 BTUH46.034.072.0800.0
PZAT4SPZAT4S49,200 BTUH46.034.072.0850.0
PZAT4.5SPZAT4.5S51,600 BTUH46.034.072.0875.0
PZAT5SPZAT5S55,200 BTUH46.034.072.0900.0
PZAT7SPZAT7S75,600 BTUH75.034.072.01100.0
PZAT8SPZAT8S84,000 BTUH75.034.072.01150.0
PZAT9SPZAT9S98,400 BTUH75.034.072.01250.0
PZAT11SPZAT11S112,400 BTUH75.034.072.01300.0

Air-Cooled Process Chillers, Packaged, Dual Stage Scroll, with Tank

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
PZAT7DPZAT7D73,200 BTUH75.034.077.01100.0
PZAT9DPZAT9D96,000 BTUH75.034.077.01200.0
PZAT9.5DPZAT9.5D102,000 BTUH75.034.077.01250.0
PZAT10DPZAT10D108,000 BTUH75.034.077.01250.0
PZAT13DPZAT13D147,000 BTUH85.040.077.01300.0
PZAT15DPZAT15D167,000 BTUH85.040.077.01400.0
PZAT18DPZAT18D190,800 BTUH85.040.077.01450.0
PZAT22DPZAT22D264,000 BTUH75.065.077.01450.0
PZA22DPZA22D264,200 BTUH66.075.051.01150.0
PZA26DPZA26D302,000 BTUH180.046.054.02600.0
PZA35DPZA35D406,000 BTUH180.088.054.02900.0
PZA43DPZA43D500,000 BTUH180.088.054.03200.0

Water-Cooled Process Chillers, Packaged, Single Stage Scroll, with Tank

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
PZWT1SPZWT1S12,100 BTUH36.034.064.5550.0
PZWT1.5SPZWT1.5S19,200 BTUH36.034.064.5600.0
PZWT2SPZWT2S22,200 BTUH36.034.064.5650.0
PZWT2.5SPZWT2.5S34,300 BTUH36.034.064.5700.0
PZWT3SPZWT3S40,300 BTUH36.034.064.5800.0
PZWT4SPZWT4S49,300 BTUH46.034.069.0850.0
PZWT4.5SPZWT4.5S52,000 BTUH46.034.069.0875.0
PZWT5SPZWT5S60,100 BTUH46.034.069.0900.0
PZWT7SPZWT7S78,200 BTUH46.034.065.01100.0
PZWT8SPZWT8S88,500 BTUH75.034.070.01150.0
PZWT9SPZWT9S104,000 BTUH75.034.070.01250.0
PZWT11SPZWT11S129,500 BTUH75.034.070.01300.0

Water-Cooled Process Chillers, Packaged, Dual Stage Scroll, with Tank

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
PZWT7DPZWT7D80,600 BTUH75.034.070.01350.0
PZWT9DPZWT9D98,600 BTUH75.034.070.01400.0
PZWT9.5DPZWT9.5D104,000 BTUH75.034.070.01450.0
PZWT10DPZWT10D120,200 BTUH75.034.070.01500.0
PZWT13DPZWT13D156,400 BTUH75.034.070.01700.0
PZWT15DPZWT15D177,000 BTUH85.034.070.01800.0
PZWT18DPZWT18D208,000 BTUH85.034.070.01900.0
PZWT22DPZWT22D259,000 BTUH85.034.070.02100.0
PZW26DPZWT26D326,250 BTUH85.034.059.02600.0
PZW35DPZWT35D460,000 BTUH85.034.059.02900.0
PZW43DPZWT43D556,000 BTUH100.034.059.03200.0

Air-Cooled Process Chillers, Split-system, Single Stage Scroll, with Tank

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
IEZAT1SIEZAT1S14,000 BTUH36.034.065.0550.0
IEZAT1.5SIEZAT1.5S18,000 BTUH36.034.065.0600.0
IEZAT2SIEZAT2S22,000 BTUH36.034.065.0650.0
IEZAT2.5SIEZAT2.5S28,800 BTUH36.034.065.0700.0
IEZAT3SIEZAT3S36,000 BTUH36.034.065.0800.0
IEZAT4SIEZAT4S49,200 BTUH46.034.068.5850.0
IEZAT4.5SIEZAT4.5S51,600 BTUH46.034.068.5875.0
IEZAT5SIEZAT5S55,200 BTUH46.034.068.5900.0
IEZAT7SIEZAT7S75,600 BTUH75.034.068.51100.0
IEZAT8SIEZAT8S84,000 BTUH75.034.070.01150.0
IEZAT9SIEZAT9S98,400 BTUH75.034.070.01250.0
IEZAT11SIEZAT11S122,400 BTUH75.034.070.01300.0

Air-Cooled Process Chillers, Split-system, Dual Stage Scroll, with Tank

Model No.Data Sheet DownloadCooling CapacityLength InchesWidth InchesHeight InchesWeight LBS
IEZAT7DIEZAT7D73,200 BTUH75.034.070.01350.0
IEZAT9DIEZAT9D96,000 BTUH75.034.070.01400.0
IEZAT9.5DIEZAT9.5D102,000 BTUH75.034.070.01450.0
IEZAT10DIEZAT10D108,000 BTUH75.034.070.01500.0
IEZAT13DIEZAT13D147,000 BTUH75.034.070.01700.0
IEZAT15DIEZAT15D167,000 BTUH75.034.070.01800.0
IEZAT18DIEZAT18D190,800 BTUH85.034.070.01900.0
IEZAT22DIEZAT22D238,800 BTUH85.034.070.02100.0
IEZA26DIEZA26D302,000 BTUH85.034.042.01500.0
IEZA35DIEZA35D406,000 BTUH85.034.042.01600.0
IEZA43DIEZA43D500,000 BTUH85.034.042.01700.0
